Metcal HCT-1000 hot air gun
Metcal HCT-1000 hot air gun
- HCT-1000 programmable handheld hot air gun
- HCT-1000 is a fully programmable handheld hot air gun that allows for quick and easy disassembly and replacement of SMT components.
- HCT-1000 is an excellent multifunctional hot air repair tool. It can be used alone or as part of the MRS-1000 modular repair system for more complex applications.
DESCRIPTION
HCT-1000 programmable handheld hot air gun
- HCT-1000 is a fully programmable handheld hot air gun that allows for quick and easy disassembly and replacement of SMT components.
- HCT-1000 is an excellent multifunctional hot air repair tool. It can be used alone or as part of the MRS-1000 modular repair system for more complex applications.
Main features and advantages:
- Integrate vacuum pick-up device for easy removal of components;
- Creating data analysis graphs facilitates repetitive operations for operators and can store up to 50 user-defined data analysis graphs;
- Quickly set manual mode;
- External thermocouples used for process setup and validation;
- Handheld controller for heaters and vacuum pickup devices;
- Programmable, digitally controlled airflow for repetitive welding effects;
- Multiple operating modes: manual, 4-zone heating (using MRS-1000 system);
- When used as part of an MRS system, HCT-1000 is connected to PCT-1000 via a cable;
- Can be used in conjunction with ATH-1000 adjustable tool holder
| Part number | describe |
| HCT-1000 | Programmable handheld hot air gun |
| Including: HCT-PS1000 | HCT-1000 power host |
| HCT-HV1 | Hot air handle component |
| HCT-FS2 | Foot switch, dual channel, HCT-1000 |
| HCTA-VC50-5 | Vacuum suction cup, 3/16 inch, 5 per pack |
| HCTA-VC64-5 | Vacuum suction cup, 1/4 inch, 5 per pack |
| HCTA-VC80-5 | Vacuum suction cup, 5/16 inches, 5 pieces per pack |
| HCTA-VC11-5 | Vacuum suction cup, 7/16 inch, 5 per pack |
| HCTA-TH1 | Handheld tool holder |
| AC-TCK-24-36 | Thermocouple |
| HCTA-CC | Communication cable |
| HCT-HTRASSY | heater block |
Technical specifications:
| size | 229 * 178 * 152 millimeters |
| weight | 5.4 kilograms |
| Rated power | 600 watts |
| input voltage | 100-240V AC, 50/60HZ |
| storage | The temperature ranges from 0C to 50C |
| airflow | 5-25l/minute |
| temperature range | Up to 450C |
| Vacuum pump | 15 inches of mercury |
| Noise level | <55db |
There are 14 types of nozzles available for use with MRS-1000/HCT-1000. These nozzles are suitable for repairing components of various sizes, including but not limited to BGA, QFP, LGA, PLCC, and SOIC parts. We also offer customized nozzles.
| Part number | Departmental size components |
| HN-B0707 | 7mm X 7mm, CSP, LGA44 |
| HN-B1010 | 10mm X 10mm, CSP, LGA178, LCC28 |
| HN-B1414 | 14mm X 14mm |
| HN-B1408 | 14mm X 8mm, CSP, SOIC24M |
| HN-B1515 | 15mm X 15mm, BGA |
| HN-B1818 | 18mm X 18mm, PLC44, CSP, TQFP100, BGA |
| HN-B2525 | 25mm x 25mm, BGA , PLCC68 |
| HN-B1809 | 18.2mm X 8.5mm, SOLJ28, SOIC28M, TSOP32 |
| HN-B2519 | 24.5mm X 18.5mm, QFP100, QFP80 |
| HN-B2727 | 27mm X 27mm, BGA |
| HN-B3232 | 32mm X 32mm, BGA |
| HN-B3535 | 35mm X 35mm, BGA |
| HN-B4040 | 40mm X 40mm, BGA |
| HN-J0005 | 5mm Round nozzle, DISCRETE |
The system is equipped with a 5mm nozzle and nozzle connector, and also offers a range of nozzles of different specifications.
